• Direct fit for the 2005–2006 Pontiac GTO
• Reduces coolant temperatures by +15°F (+6°C)
• Large two-row brazed aluminum core increases fluid capacity by 0.64 L and provides ideal coolant temperatures on and off the track
• All-aluminum construction with TIG-welded end tanks provides optimal heat dissipation and reliability
• Applicable for both manual and automatic vehicles
• Includes magnetic drain plug and 1.3 bar high-pressure radiator cap
• Mishimoto Lifetime Warranty

Material Aluminum

Note This item is for manual and automatic transmission vehicles. This radiator will fit with Svede and other aftermarket OTR cold-air intakes.

Due to the added thickness of the Mishimoto radiator, the clip securing the radiator cover to the electric fan shroud will need to be trimmed for proper fitment. The remaining clips securing the radiator cover to the core support will sufficiently secure it in position.

Engine Codes LS-2 (6.0L)

Fits 2005–2006 Vauxhall Monaro (5.7L/6.0L)

2005–2006 Holden Monaro (6.0L Engine Only)

Overall Height 31.95"

DPI 2987

Drain Plug Length 1.5mm

Drain Plug Thread Size (M12)

Overall Length 19.65"

Tank Wall Thickness 0.08"

Outlet 1.375"

Rows 2

Inlet 1.375"

Coolant Capacity 3.58

Dual Pass False

Purchase Includes Mishimoto Radiator

Mishimoto Radiator Cap

Magnetic Drain Plug

Mishimoto Lifetime Warranty

Overall Width 6.38"

Core Length 26.55"

Core Height 17"

Core Size 26.55" x 17.00"

Core Thickness 1.96"
